Chassis
VL01 NQR
GVW(ton)
8.5
Engine
ISUZU 4HG1
Cylinders/displacement (cm3)
4600
Output (Hp)
121 @ 3200 rpm
Torque (Nm)
304 @ 1600 rpm
Gearbox
Manual gearbox with 5 forward speeds & 1 reverse speed
Service Brake (Front & Rear)
Drum, hydraulic dual circuit, hydraulic brake boster & exhaust brake
Parking Brake
Mechanical
Front axle
Rigid type
Rear axle
Rigid type
Steering
Power steering with tilt - telescoping steering wheel
Wheel rim
Steel
Tires (front & rear)
7.50-R16-14
Fuel tank capacity
100L
Batteries
2x12V -140AH
Overall length (mm)
8,220
Overall width (mm)
2,350
Overll height (mm)(1)
2,886
Overll height with A/C (mm)
3,030
Wheelbase (mm)
4,175
Internal height (mm):
1935
Luggage space (m3)
2.7
Total passengers (max)
33 seats
Floor type
Wooden vinyl
Driver Door
standard
Co-driver door
standard
Number of doors
1
Type of pass. Door
Swing-in type
Door actuation
Electrically
Windscreen
Triplex Glass
Side windows
VG10 Tempered glass with Sliding openning
Rear window
VG10 Tempered glass
Mirrors
Luxury manual Side Mirror
Roof hatches
Standard
A/C system
A/C with air outlet & light for each seat
Upholstery
Fabric
Back rest accessories
Magazine net , Ashtary, Grip handle ,Foot rest
Time clock
Yes
Interior lighting
Continios LED light with ambiant light
Entertainment electronics
DVD,one 19 "monitor
Parcel rack
YES
driver Locker
with driver Locker + rack locker
USB
Driver, Co-driver and passengers
Rim Cover
yes
Sunvisor
Windscreen & driver side Sunvisor
Roof hatches
Emergency Exit type
Destination panels
Front & Side
Fog Lights
YES
Driver Mic
with driver mic
Wifi
TP-Link router
GPS
GPS preparation
Driver Controls
10'' Rugged type android Tablet
Ambient light in Saloon and Dashboard
RGB type
CCTV with DVR
Saloon , road and reverse camera
Engine
Mercedes-Benz OM 460 – Euro III version
Max Output
290 KW (394 HP) at 1600 rpm
Max Torque
1900 N.m. at 1117 rpm
Total Displacement
12816 cm3
Clutch
Double dry plate clutch
Front Axle
Mercedes-Benz, double steered front axles; 7500 kg max. permissible load per axle; Parabolic springs 7.5 ton max. capacity per axle; Stabilizer.
Rear Axle
Mercedes-Benz, double rear axle (tandom); 13400 kg max. permissible load per axle; Parabolic springs 16 ton max. capacity per axle; Differential rear lock.; Axle ratio i = 4.333 : 1
Steering
Servotwin steering 4 axle. Cruise control
Rim Size
9.0 x 22.5”
Tyre Size
315/80 R 22.5
GVW
41800 kg
Cabin
Standard S-cab
